| Part NO. | Material | Lens Color | Iv(mcd) | Viewing Angle | λp | |
|---|---|---|---|---|---|---|
| Min. | Typ. | |||||
| LL-503HD2E-002 | GaP | Diffused | 1 | 4 | 35 | 700 |
| LL-503ID2E-001 | GaAsP | 18 | 40 | 35 | 644 | |
| LL-503SD2E-010 | AlGaAs | 50 | 110 | 35 | 660 | |
| LL-503UD2E-004 | AlGaAs | 130 | 270 | 35 | 660 | |
| LL-503VD2E-015 | AlGaInP | 800 | 1700 | 34 | 644 | |
| LL-503VM2E-011 | AlGaInP | White Diffused | 1500 | 3000 | 30 | 635 |
| LL-503HT2E-001 | GaP | Transparent | 10 | 25 | 18 | 700 |
| LL-503IT2E-005 | GaAsP | 140 | 310 | 24 | 644 | |
| LL-503ST2E-007 | AlGaAs | 250 | 600 | 17 | 660 | |
| LL-503UT2E-006 | AlGaAs | 2000 | 4200 | 30 | 648 | |
| LL-503VT2E-009 | AlGaInP | 2500 | 5000 | 17 | 632 | |
| LL-503HC2E-003 | GaP | Water Clear | 120 | 260 | 12 | 676 |
| LL-503IC2E-001 | GaAsP | 130 | 300 | 15 | 644 | |
| LL-503SC2E-008 | AlGaAs | 200 | 420 | 18 | 660 | |
| LL-503UC2E-006 | AlGaAs | 800 | 2000 | 15 | 660 | |
| LL-503VC2E-087 | AlGaInP | 4000 | 10000 | 13 | 636 | |
| LL-503GD2E-008 | GaP | Diffused | 20 | 50 | 35 | 568 |
| LL-503GD2E-059 | GaP | 80 | 160 | 31 | 568 | |
| LL-503GT2E-004 | GaP | Transparent | 50 | 120 | 17 | 564 |
| LL-503GT2E-009 | GaP | 400 | 800 | 18 | 572 | |
| LL-503GC2E-024 | GaP | Water Clear | 250 | 550 | 15 | 568 |
| LL-503GC2E-044 | AlGaInP | 1400 | 2800 | 15 | 572 | |
| LL-503YD2E-045 | GaAsP | Diffused | 50 | 100 | 31 | 588 |
| LL-503YT2E-016 | AlGaInP | Transparent | 1600 | 3800 | 17 | 592 |
| LL-503YC2E-014 | AlGaInP | Water Clear | 1600 | 4000 | 15 | 592 |
| LL-503YC2E-011 | AlGaInP | 3000 | 6800 | 16 | 592 | |
| LL-503AT2E-007 | AlGaInP | Transparent | 1200 | 2500 | 30 | 605 |
| LL-503AC2L-009 | AlGaInP | Water Clear | 700 | 1500 | 30 | 605 |
| LL-503AC2E-005 | AlGaInP | 1300 | 3000 | 15 | 610 | |
| LL-50ABD2E-007 | InGaN | Diffused | 210 | 460 | 50 | 468 |
| LL-50ABM2E-002 | InGaN | Diffused | 460 | 1100 | 40 | 468 |
| LL-503BM2E-005 | InGaN | White Diffused | 400 | 1000 | 20 | 468 |
| LL-50ABC2E-A01 | InGaN | Water Clear | 3300 | 7300 | 15 | 465 |
| LL-50ABC2E-B02 | InGaN | 460 | 1000 | 30 | 468 | |
| LL-50ABC2E-112 | InGaN | 4500 | 8500 | 25 | 465 | |
| LL-50AZC2E-118 | InGaN | 8000 | 18000 | 15 | 520 | |
| LL-50AZC2E-122 | InGaN | 7300 | 16500 | 30 | 520 |
